RAIN GAUGE
TEMPERATURE AND HUMIDITY SENSOR
WIND SENSOR
1. Rain collector
2. Tipping bucket
3. Rain sensor
4. Drain holes
1. Sensor shield
2. Temperature and
humidity sensor
1. Wind cups (anemometer)
2. Wind vane
1
1
1
2
2
2
3 4
