User Manual
CBX-1 / CBX-2
3. Initial Operation
The initial operation consists of the necessary steps to make a height-adjustable
desk actually height adjustable with the CBX motor control. Prerequisites are:
• The CBX control box is mounted (according to the instructions in chapter 2).
• The desk has to be prepared for height-adjustment.
Danger: The initial operation of the control box must be carried out by
qualified personnel only!
3.1 CBX Interfaces
The motor control box CBX (CBX-1 is capable of driving 1 motor) is equipped with
following interfaces:
Fig.3 - Interfaces
c
Interface to handset (HS)
d
Interface to motor 1 (M1)
e
Interface to motor 2 (M2)
f
Mains supply
Note: A squeeze line can only be connected by means of an optionally
available module!
Page 10/29
