User Manual
CBX-1 / CBX-2
1.3. Performance Differences CBX-1 / CBX-2
CBX-1 The motor control box CBX-1 is suitable to control 1 motor for desk
height adjustment.
CBX-2 The motor control box CBX-2 is suitable to control up to 2 motors for
desk height adjustment.
Note: Further differences are listed in the CBX-1 and CBX-2 datasheets!
1.4. Audience and Previous Knowledge
This user manual is intended for the following audience:
• Assembly personnel, which assembles and starts-up the height-adjustable desks
(mount control box and motors, configure the control box, etc.)
• Furniture assembly personnel, service personnel, which puts the desks into
operation on site in showrooms or directly at the end customer's place
To put into operation, mount and configure height-adjustable desks with the CBX
control box, following skills are prerequisite:
• Basic mechanical and electronics skills
• Lecture of this manual
Page 4/29
