LOGICDATA CBX-1 User Manual

User Manual
CBX-1 / CBX-2
5. Technical Data
General
Supply Voltage
110V ±6% / 60 Hz
Standby-Consumption primary 1,1 W
Operating Voltage Electronics
5VDC ±5% 150mA
Hall Sensor Operating Voltage
5VDC ±10% 150mA
Ambient Temperature 0 - 35°C
Operation Humidity 5 – 85% (non condensing)
Storage Humidity 5 – 90% (non condensing)
Protection Class II
Mains Cable 3 m
Dimensions (L, B, H) [mm] 203 x 107 x 53
Technial Data CBX-2-XXX-220VA
Switching Capacity 10% (1 min. on / 9 min.
off)
220VA / 9A / 24V @ 25°C
Weight 1,9 kg
Technial Data CBX-1-XXX-220VA
Switching Capacity 10% (1 min. on / 9 min.
off)
220VA / 9A / 24V @ 25°C
Weight 1,8 kg
Technial Data CBX-1-XXX-140VA
Switching Capacity 10% (1 min. on / 9 min.
off)
140VA / 6A / 24V @ 25°C
Weight 1,2 kg
Page 22/29
