5.7 COMPLETING ASSEMBLY
Before you use the table, you must perform a Position Reset Procedure
CAUTION
Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive during acceleration/deceleration and reset pro-
cesses. This may lead to minor or moderate injury through crushing.
• Ensure that no persons or objects are in the table's range of motion
It is possible to perform a Position Reset Procedure with all types of compatible User Interface. However, this
section describes performing a Position Reset Procedure for Table Systems controlled by a Handset with an
UP Key and DOWN Key (Comfort or Basic Handsets).
If your DYNAMIC MOTION system is operated by a dierent User Interface, consult that product’s operating
Manual for instructions on performing a Position Reset Procedure.
1. Press and hold the DOWN Key until the table stops at the lower position limit
2. Release the DOWN Key
3. Press and hold the DOWN Key again
The table will move down slightly, then up again
4. Release the DOWN Key
The Position Reset Procedure is complete.
INFO If your DYNAMIC MOTION system has been parameterized with additional stop-
ping points (e.g. a Safety Area or Container Stop Position), repeat Step 3 until the
table has moved upwards again.
INFO In some cases, especially during rst start-up, the lower position limit will be inac-
tive. In this case stop the Position Reset Procedure as soon as the table has moved
to its lowest position and then slightly upwards again.
