18
100A 10A 20A
5.1 Fuses - replacement
There are 3 fuses in the electrical circuit, located behind the plate with this
pictogram.
• 10 Amp fuse in the control current circuit
• 20 Amp fuse for built-in charger
• 100 Amp fuse in the main supply from battery
Replacement:
The old fuse is to be removed and replaced by a new one of the same size.
Find out why the fuses blow!
5.2 Wirring connections
Many operational disturbances are caused by bad connections in the
electrical circuit. Make sure that the connections are in order.
Check connections regularly for damage at insulating caps or bad connections
at plugs etc. Verdigris must be removed from cable plugs. Keep all screw/nut
connections tight.
5.0 There must be a current supply...
