logitrans LOGIFLEX SELF1003 - Default Chapter; Table of Contents

3
Contents
1.0 Before the rst lift... .............................................................................................. 4
2.0 Functions and identications .......................................................................... 5
3.0 How to operate the Logiex ............................................................................. 6
3.1 Handling of pallets ............................................................................................................... 6
3.2 Use of Logiex ..................................................................................................................... 8
3.3 Handle functions .................................................................................................................. 8
3.3.1 Multiex function ........................................................................................................... 10
3.3.2 The safety switch............................................................................................................11
3.4 Battery Info display ............................................................................................................ 12
3.4.1 BDI ................................................................................................................................ 12
3.4.2 Machine operating hours ............................................................................................... 12
3.4.3 Faults ............................................................................................................................ 13
3.4.4 State of operation LED’s ............................................................................................... 13
4.0 Optimum safety .....................................................................................................14
4.1 Safety regulations .............................................................................................................. 14
4.2 Marking .............................................................................................................................. 15
4.3 Transport with load ............................................................................................................ 16
4.4 Avoid overloads ................................................................................................................. 16
4.5 Emergency stop................................................................................................................. 17
4.6 Personal safety .................................................................................................................. 17
5.0 There must be a current supply... ............................................................... 18
5.1 Fuses - replacement .......................................................................................................... 18
5.2 Wirring connections ........................................................................................................... 18
6.0 Long live the Logiex ......................................................................................... 19
6.1 Lubrication and hydraulic oil .............................................................................................. 19
6.2 Oil change ......................................................................................................................... 20
6.3 The hydraulic pump .......................................................................................................... 21
6.4 Fork adjustment ................................................................................................................. 21
6.5 Adjustment of lifting chain .................................................................................................. 22
6.6 Adjustment of side play...................................................................................................... 23
6.7 Cleaning ............................................................................................................................ 24
7.0 Fault codes/Fault location key ...................................................................... 25
7.1 Fault codes - Battery info display ...................................................................................... 25
7.2 Fault location key............................................................................................................... 26
7.3 Remedy ............................................................................................................................. 28
8.0 Good service after purchase ......................................................................... 30
8.1 Ordering spare parts.......................................................................................................... 30
8.2 Warranty/Compensation .................................................................................................... 30
8.3 Service and repair ............................................................................................................. 30
8.4 Warranty ............................................................................................................................ 30
8.5 Liability exemption ............................................................................................................. 30
