28
7.3 Remedy
1. Check to ensure that the key (A) is turned clockwise and that emergency stop
(B) is not activivated.
2. Charge battery - (see separate instruction manual for battery and charger)
Access to the battery is achieved by tipping the cover (C).
• If necessary, check the liquid level in battery cells.
• The remaining capacity of the battery can be checked with an acidometer
3. Check switch (D). Check cable connections on switch.
4. Check control current fuse (F).
• If the fuse is intact and the stacker does not drive, contact the dealer.
5. Check main fuse (G)
Check cable connections on drive motor and pump motor. If no fault can be
found and the stacker does not drive, contact the dealer.
6. Check battery, (see point 2 above).
7. Check the wheel motor. The wire connection for the brake is checked.
These must be connected. If no fault can be found and the stacker still brakes,
contact the dealer.
8. Brake needs adjustment. The brake force is adjusted by turning the adjusting
screw on the outside of the brake. The brake force is increased by tightening
clockwise.
9. Remove battery and replenish oil (see point 6.2).
If the stacker cannot lift max load contact the dealer.
10. Contact the dealer.
11. Locate the oil leak and contact the dealer.
To localise the leak it is necessary to remove the rear cover (E).
12. Check the fuse for the charger (J)
If the fuse is intact and the stacker does not charge, contact the dealer.
7.0 Fault codes/Fault location key
