Configuring the UTRED-16 for logging UTRED-16 User Guide 13
File Settings
Select the File Settings tab to select which files are generated when the UTRED-16 is
plugged into a computer's USB port, and what information these files contain. Select as
many file formats as you wish to generate.
Parameters that influence the appearance of all files are:
l setting the temperature units
The temperature unit for the PDF file is also used for the units shown on the
display.
l setting the date and time format
l configuring time zone and MKT values
l setting the language
Parameters specifically influencing the appearance of the PDF file are:
l scaling parameters for the chart
l showing or hiding grid lines
l showing or hiding alarm threshold lines
l generating the data list
For detailed information about each parameter please read the section about Configuring a
LogTag
®
for logging in LogTag
®
Analyzer’s User Guide or press F1 for help.
The PDF file can not only be viewed in a PDF viewer, but can also be opened with
LogTag
®
Analyzer directly.
Advanced Configuration Settings
Select Advanced Settings for additional configuration settings. These settings decide how
some of the elements are displayed on the unit's own display and set certain options
specific to the UTRED-16.
