Display Overview UTRED-16 User Guide 17
Display Overview
ALARM/OK indicator
The symbol is shown as soon as the UTRED-16 has registered an alarm event.While there are no
alarms, the symbol is shown.
Recording indicators
The recording indicators show what the UTRED-16 is currently recording.
l If READY is shown, the UTRED-16 is ready to be started with the START/Mark button.
Depending on the configuration it may already record pre-start readings.
l If STARTING is shown, the logger has been started, and a start delay is active. The word
DELAY is also shown, together with the time in hours and minutes until the start.
l If is shown, the UTRED-16 is recording temperature at the sample interval defined
during configuration.
l If is shown together with the word PAUSED, the product is also recording, but the
recorded values are not taken into account when calculating alarm events and durations.
l If the word STOPPED is shown, the UTRED-16 has finished recording temperature data.
Mark indicator
The word MARK is shown when the next temperature reading is identified with an inspection mark
in the recorded data.
MIN/MAX indicator
The word MAX is shown when the temperature on the display represents the maximum
recorded temperature for the current trip. The word MIN is shown when the temperature
on the display represents the minimum recorded temperature for the current trip
7
.
Temperature Units
Depending on the selected PDF temperature units, this shows either°F or°C.
7 If MIN/MAX data were reset during the trip, these temperatures reflect only the period since the reset took place.
