TAB 1
TAB 2
R134a
LP
(kg/cm
2
)
HP
(kg/cm
2
)
15,5
21,0
26,5
32,0
38,8
43,0
min..............max
0,5...............3,0
0,5...............3,0
0,5...............3,0
0,5...............3,5
0,5...............3,5
0,5...............3,5
min..............max
9,5...............13,0
12,5...............17,5
14,0...............20,5
16,0...............24,0
18,5...............25,5
22,0...............28,0
A/C pressures according to ambient temperature for R134a
REFERENCE PRESSURE TABLE
Fixed displacement compressor (F)
(es. SD5H09, SDH15)
Outside
Temperature
(°C)
TEST QTY R134a HOSE LENGHT
TEMPERATURE
EXT
SUC LOW
PRESS
DISC HIGH PRESS.
