Fig. 24 Fig. 25
Fig. 26 Fig. 27
B
M
T
F
V + R
ASSEMBLY AND INSTALLATION - 3
3.5 INSTALLATION OF THE CONDENSING UNIT
1 Disassembly to condenser unit C g. 24-25 the air plastic cover B complete with fan condenser F , unscrew and keep
the bolts N° 4 TCEI M6x16, washer ( V+R ) see g. 24
2 Place the condenser C on the back of cab and in same time to keep it in horizontal position for a correct mounting.
To mark the four point L on the condenser bracket needful to x the four threaded insert T (supplied) g. 27 like
measurements reported in g. 26
3 Use a drill to 9 mm, and to drill the four points marked for x the four threaded insert T, x the insert threaded T (supplied)
on the metal cab using the specic tool M (not supplied) see g.27
