GENERAL DESCRIPTION AND TECHNICAL DATA - 2
2.1 TECHNICAL CHARACTERISTICS
Table of technical data
Air-conditioning system
Model
350 “C” - AUS
Dimensions and weight Power unit Condenser Split (diffuser)
Length 710 mm 560 mm 560 mm
Height 560 mm 360 mm 360 mm
Depth 290 mm 120 mm 140 mm
Weight 110 kg * 6 kg 10 kg
* Without support structure
350 “C” AUS
Fuel Diesel for automotive use
(taken from the vehicle’s own tank for
models installed directly in vehicles)
Maximum fuel consumption 0,7 litre/ h
Cooling capacity 13.000 btu/h (3.800 W)
Coolant R-134a
Quantity of coolant min 1000 ÷ max 1200 gr. *
The amount of gas may vary according to pipe length see
Tab. 1 and Tab. 2
Optimum operating pressure: Delivery pressure HP = 14 ÷ 17 bar - @ 30° C ext. temp.
Intake pressure LP = 1 ÷ 3 bar - @ 30° C ext. temp.
ATTENTION !!!
It is important to comply with the above quantities.
Non-observance of this recommendation could compromise the performance of the system
Onboard electrical power supply
12 V 24 V
Battery recharge capacity (alternator)
70 A - MAX 40 A - MAX
Evaporator airow
600 m
3
/h - MAX 600 m
3
/h - MAX
Control system power supply
12 Vdc 24 Vdc
