G
B
Fig. 86
3 - ASSEMBLY AND INSTALLATION
3.10 FASTENING THE PIPES AND CABLES - Fixed cab version
V cab
C condenser
S split unit
PU power unit
PS access points gas
B Battery
CONDENSER/CAB METHOD
Pipe G10
Pipe G8
SPLIT cable
battery cable
Pipe G6
Step Description
1 After xing the Power Unit / Condenser / Split unit, proceed to fasten and close pipes and cables, according to the
following two procedures ( g 86).
B
