4 - DIAGRAMS AND WIRING
COMPLETE CABLE HARNESS SYSTEMS 12 Volt - COD. 7971.126
ITEMS
NAME DESCRIPTION SAPRISA P.N. LOMBARDINI P.N.
ALT ALTERNATOR
ATS AMBIENT TEMP SENSOR
BAT BATTERY
COMP COMPRESSOR
EC EXTENSION CORD EC02 2186 286 8
ECC CONTROL PANEL L801 2183 295 8 ECU ELECTRONIC CONTROL UNIT K042 2183 294 8
ETS EXTERNAL TEMP SENSOR
F1 COND. UNIT FAN F2 SPLIT FAN F8 FUSE
GPS GAS PRESSURE SWITCH
GTS GAS TEMP SENSOR
OPS OIL PRESSURE SWITCH
OTS OIL TEMPERATURE SWITCH
PC POWER CABLE EC01 2186 286 8
RC IRDA REMOTE CONTROL L811 9141 006 8
SC SPLIT CABLE EC03 2186 287 8
SM STARTER MOTOR
CONNECTORS
LETER NAME / DESCRIPTION BRAND P.N.
X1 2 WAYS SUPERSEAL 1,5 SERIES HOUSING PLUG AMP 282080-1 X2 1 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282079-2
X2a 1 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282103-1
X3 1 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282080-1 X4 2 WAYS SUPERSEAL 1,5 SERIES HOUSING PLUG AMP 282080-1
X4a 2 WAYS SUPERSEAL 1,5 SERIES HOUSING TAB AMP 282104-1
X5 1 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282080-1
X5a 1 WAYS SUPERSEAL 1,5 SERIESHOUSING TAB AMP 282103-1
X7 4 WAYS SEALED CONNECTOR 1620 SERIES SAPRISA 1824 + 1822 X9 6 WAYS FEMALE HOUSING SICMA SERIES FCI 211PC08980049
X11 24 WAYS FEMALE HOUSING SICMA SERIES FCI 211PC24950005 + 211A247001
X11a 24 WAYS MALE HOUSING SICMA SERIES FCI 211PC249S03
X12 2 WAYS METRIPACK SERIES 280 FEMALE DELPHI 15300027
X12a 2 WAYS METRIPACK SERIES 280 MALE DELPHI 15300002
X13 2 WAYS SUPERSEAL 1,5 SERIES HOUSING PLUG AMP 282080-1
X13a 2 WAYS SUPERSEAL 1,5 SERIESHOUSING TAB AMP 282104-1
X14 24 WAYS FEMALE HOUSING SICMA SERIES FCI 211PC249S0005 + 211A247001
X14a 24 WAYS MALE HOUSING SICMA SERIES FCI 211PC249S0003
X15 24 WAYS FEMALE HOUSING SICMA SERIES FCI 211PC249S0005 + 211A247001 X16 2 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282080-1
X16a 2 WAYS SUPERSEAL 1,5 SERIESHOUSING TAB AMP 282104-1
X17 2 WAYS SUPERSEAL 1,5 SERIESHOUSING PLUG AMP 282080-1
X17a 2 WAYS SUPERSEAL 1,5 SERIESHOUSING TAB AMP 282104-1
X18 2 WAYS METRIPACK SERIES 280 FEMALE DELPHI 15300027
X18a 2 WAYS METRIPACK SERIES 280 MALE DELPHI 15300007
X20 FASTON 6,35 FEMALE ISOLATED - - X21 FASTON 6,35 FEMALE ISOLATED - - X22 PLUG 80A 160V (MALE TERMINAL) REMA
X22a SOCKET 80A 150V (FEMALE TERMINAL) REMA
