23
THIS MANUAL IS PROPRIETY OF ECOWIND by LOMBARDINI - ALL FORMS OF REPRODUCTION, PARTIAL OR OTHERWISE, IS STRICTLY PROHIBITED
G
B
Fig. 21
Fig. 22
Fig. 23
oil drain hole
3 - ASSEMBLY AND INSTALLATION
Attention !!!
When the Power Unit has been fixed, it is
advisable to rmly tighten the eyebolts on the
protective casing see g. 23).
If choosing to remove them from the protective
casing, make sure to tighten the four TBEI M8x20
to support the eyebolts by following the same
procedure, in order to avoid a possible noise
increase from the diesel engine of the Power
Unit.
oil drain cap
. Note weel
In the pictures (g. 21 and g. 22) is reported the
position to oil drain for maintenance engine
