3 - ASSEMBLY AND INSTALLATION
4 Install and x the condenser C on the back of the cab using the bolts (supplied) F, TE M6x35 and washer Ø 6x18,
before the xing interpose the four spacers D 30 – H 15 (supplied) as showed in g.29-30
WARNING
If you choose for xing to condensing unit, in other position on truck (than the recommended on rear cab as before
specied), need that the new position is ensured optimum fastening and at the same time in an area where the air cooling
condenser is free to ow in the eld open to avoid damaging hot air recirculation function compromising optimal works
system!
