SECTION 4. DISASSEMBLY AND SERVICE
2) CAMSHAFT DIAMETER
3) CAMSHAFT HOLDER ID
BEARING
Clean bearing in solvent and dry it.
Spin the bearing by hand and check for play. replace
the bearing if it is noisy or has excessive play
OIL LEVEL SWITCH
Measure continuity of oil level switch with an ohmmeter.
If, when the crankcase has not enough oil or has no oil, oil
level switch’s black lead is conductive to ground wire, and
when the crankcase has enough oil, oil level switch’s black
lead is not conductive to the ground wire, it is normal.
Standard Service limit
13.984 mm 13.916 mm
Standard Service limit
14.0 mm 14.048 mm
- 28 -
