SECTION 4. DISASSEMBLY AND SERVICE
4-4-3 Generator / Ignition Coil /Recoil Starter
a. DISASSEMBLY/ REASSEMBLY
25×41.25×6
Use a special
remove. Never knock with a hammer.
REASSEMBLY:
Remove oil or any other dirty matter from
crankshaft and flywheel’s
tapered surface
before installation.
Flange nut M14
Torque: (80~90) N•m
BOLT M6×20
Torque: (8~12) N•m
REASSEMBLY:
Remove earth or grass
sticking to it
to installing direction
Re
before installing.
REASSEMBLY:
Be careful not to
damage the lip of oil
seal when inserting the
Check if the insulated cost
prior to assembly to avoid
electric leakage.
servicing, take care not
to damage the fan
blades.
