LONCIN LC3000i User Manual

SECTION 2 MAINTENANCE STANDARD
Resistance Secondary coil 5.9-7.1Ω
－
Air gap (at flywheel) 0.3-0.4
－
2-2 Generator Maintenance Standard
Table of resistance values of windings rated 230 V 2.3KW:
Part
Wire color
Resistance
Main winding
Brown
3.06Ω±15%
Power supply winding
Orange
0.42Ω±15%
DC winding
Blue
0.086Ω±15%
Table of resistance values between windings rated 120V 2.3KW:
Part
Wire color
Resistance
Main winding
Brown
0.97Ω±15%
Power supply winding
Orange
0.42Ω±15%
DC winding
Blue
0.086Ω±15%
2-3 Fastener Torque Specification
Item Thread specification Torque range(N.m)
Connecting rod bolt M6×1 12-14
Cylinder head bolt M8×1.25 32-35
Flywheel mounting nut M14×1.5 80-90
Crankcase cover bolt M8×1.25 27-30
Air cleaner mounting nut M6×1 8-12
Valve lock nut M5×0.5 5-8
Muffler mounting nut M8×1.25 20-28
Muffler mounting bolt M8×1.25 20-28
Breather chamber cap bolt M5×0.75 5-8
Starter motor fastening bolt M6×1.25 8-12
Spark plug 25-30
- 4 -
