LONCIN LC3000i User Manual

SECTION 4. DISASSEMBLY AND SERVICE
b. DISASSEMBLY/ REASSEMBLY
Reassembly:
Don’t interchange
the exhaust and
intake valves.
Reassembly:
Check exhaust valve
taper face for
chipping or excessive
carbon deposits
before assembling.
CYLINDER HEAD
Reassembly:
Check the two ends of the
push rod for wearing and
push rod for straightening.
B
e sure that two ends of
push rod completely seat
on the lifter and rocker seat.
Reassembly:
Check the contacting face of
rocker with adjust nut and
push rod for wearing before
assembling.
SEAL,GUIDE
VALVE SPRING(2)
LOCKER
VALVE SPRING RETAINER
EXHAUST VALVE
LOCKER VALVE
PUSH ROD (2)
ROCKER ARM (2)
INTAKE VALVE
VALVE LIFTER
SHAFT,
ROCKER ARM
- 30 -
