Link Mode
It is now possible to set the channel/frequency and trap number on the R4300 Receiver without using
dip switches. This operation only needs to be done once, or if you want to change the channel or
trap number. Once set, the channel and trap number are stored in memory until changed, even after
power is turned o󰀨 to the machine.
Select Option 7, System Setup
From the Main Menu, press button 7 to
select the System Setup option. You will
be prompted to enter your 4-digit password,
then press ENTER. This will bring you to the
System Setup Menu.
Solo Shooter
5
6
7
Wobble Setup
System Status
System Setup
4
1
2
Select Option 2, Chg System ID
From the System Setup Menu, press the 2
button to select the Chg System ID option.
This will bring you to the Set System IDs
Menu.
System Setup
1
2
3
Chg Password
Chg System ID
Target Mgt
Select Option 1, RF Channel
From the Set System IDs Menu, press button
1 to selec the RF Channel option. This will
take you to the Set RF Channel Menu.
Select Option 2, Link Mode
From the Set RF Channel Menu, press button
2 to select the Link Mode option. This will take
you to the Link Mode Menu.
1
2
Set System IDs
RF Channel
Msg Format
1
2
Set RF Channel
MT Channel
Link Mode
3
4
