LORCH S-Pulse User Manual

Pc-Boards
- 18 - 02.20909.2710.1-06
Overview connectors MAPRO05
Connector designation
X1 connector to power uint 1
X2 connector control transformer (supply of pc-board)
X3 connector to pc-baord DS-ERW (only used at machines with two wire feed units)
X4 connector to power uint 2
X5 connector to Interpass hose package
X6 230V supply fans/cooling unit (from control transformer)
X7 connector fan group 1 (230V AC)
X8 LorchNet connector (CAN bus)
X9 connector flow meter
X10 connector gas valve (only used when TIG option is installed)
X11 connector front panel
X13 connector cooling unit
X14 LorchNet connector (CAN bus)
X15 connector TIG torch button
X16 connector volt/amp display
X17 connector output voltage (to pc-board DP-UFI-BO)
X18 connector remote control
X19 connector gas test button
X20 LorchNet connector (CAN bus)
X21 connector JTAG interface (internal programming port)
X22 connector JTAG interface (internal programming port)
X23 connector serial Interface (RS232: internal programming port)
X25 connector fan group 2 (230V AC)
X26 connector PE and gas monitoring
Tab. 6: connectors MAPRO05
