Using the Main Menu15
5. Configure the following:
• Type: Select the address type.
• IP Address: Enter a single IP address for the selected filter type.
6. Click OK.
7. Click Apply.
15.8.6 Save System Settings to a USB Flash Drive
The system allows you to save your current system configuration to a USB flash drive (not in-
cluded). This is useful if you want to backup your current settings.
NOTE
This function only saves settings created in system menus. It does not save or backup any video.
Prerequisite:
• Connect a USB flash drive (not included) to a free USB port on the unit.
To save system settings:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click SYSTEM, then click the CONFIG BACKUP tab.
#LX400111; r. 5.0/56647/56647; en-US 77
