REMOTE CONTROL:
Features of the Remote Control. For more details on specific remote control features, refer
to the Monitor features
KEY FUNCTION DESCRIPTION
Cuts off the sound from the camera
Turns Power to monitor ON/OFF
1-8 Allows user to select individual cameras
Quad 1/2 Sets monitor to Quad mode (P1/P2)
FRZ 1/5 Freezes the Full-Screen of either Ch 1 or 5
FRZ 2/6 Freezes the Full-Screen of either Ch 2 or 6
FRZ 3/7 Freezes the Full-Screen of either Ch 3 or 7
FRZ 4/8 Freezes the Full-Screen of either Ch 4 or 8
FREEZE Used to freeze the current screen
DEMO Displays various functions in sequence
Changes channel up
UP Arrow Key in Menu and Zoom
Changes channel down
DOWN Arrow Key in Menu and Zoom
Increases the audio volume
RIGHT Arrow Key in Menu and Zoom
Decreases the audio volume
LEFT Arrow Key in Menu and Zoom
MENU Brings up the Main Menu
PIP/POP Display either PIP/POP screen
SEQ / SUB1 Automatic channel scan /
Changes sub screen in PIP mode
VCR / SUB2 Sets monitor to VCR mode /
Changes second sub screen in PIP mode
AUDIO 1/5 Selects sound of either Channel 1/5
AUDIO 2/6 Selects sound of either Channel 2/6
AUDIO 3/7 Selects sound of either Channel 3/7
AUDIO 4/8 Selects sound of either Channel 4/8
ALARM OFF Turns the Alarm sound OFF
PIP SEQ Sequence in PIP/POP mode
ZOOM / MAIN Sets monitor to Zoom feature /
Changes Main screen in PIP mode
-13-
