STANDARD WIRED CAMERA:
1. Camera Lens – Delivers high quality image by using a 1/4” CCD Image Sensor
2. LED’s - 6 Blue LED’s for day/night vision
3. Speaker – Delivers sound from the monitor to the camera
4. Camera Input – Connect cable to monitor
5. Bracket – Metal bracket connects to camera for mounting to walls, ceilings or table
6. Microphone – Picks up sound around the camera
INSTALLATION
A. Camera Unit
Permanent installation using metal camera bracket
IMPORTANT NOTE:
Keep camera installed away from direct sunlight. Also avoid places where humidity
is high or unable to protect rain. The mounting bracket must be attached to a structural
device such as wall stud or ceiling rafter using suitable fastener.
-14-
1
3
4
5
6
2
To Next Page
