Using the Main Menu16
3. Check Enable to allow FTP connection, and select either FTP or SFTP depending on your
configuration.
4. Configure the following:
• Host IP: Enter the FTP server’s address.
• Port: Enter the FTP port.
• Username: Enter your FTP username.
• Password: Enter your FTP password.
• Anonymous: Enable if your FTP server supports anonymous login.
• Remote Directory: Enter the directory to save recordings and/or snapshots to.
• File Length: Enter the recording file length in minutes.
• Image Upload Interval: Enter the interval between snapshots in seconds.
• Channel: Select a channel to set FTP recording preferences for.
• Weekday: Select a day of the week to configure FTP recording settings for, or select All to
apply to all days of the week.
• Period: Select up to 2 periods of time where the system will save recordings to the FTP.
Check Alarm, Motion, or Continuous beside each period to determine which recording
type will be uploaded to the FTP.
5. Click Apply.
16.4.6 Configuring Switch Settings (Advanced)
Configure the networking settings for the internal PoE switch.
CAUTION
It is recommended to leave this menu on the default settings. Changing the information in this menu may disrupt
the connection to the cameras.
To configure switch settings:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click
, then click NETWORK. Click the Switch Settings tab on the side panel.
3. Configure the IP Address, Subnet Mask, and Default Gateway for the internal PoE switch.
4. Click OK. Click Save to save changes. The system will restart.
#LX400113; r. 2.0/56306/56316; en-US 81
