Lowrance GlobalNav 310 - Dgps Receiver

41
TO GLOBALNAV 310
OTHER
DEVICE
12 VDC
BATTERY
BLACK WIRE
GROUND WIRES
WHITE WIRE
RED WIRE
TO +12V
OTHER
DEVICE’S
RECEIVE
DATA WIRE
GLOBALNAV 310’S
WIRES
OTHER DEVICE’S
WIRES
GLOBALNAV 310
TRANSMITTING NMEA
DATA TO ANOTHER DEVICE
TO GLOBALNAV 310
DGPS
RECEIVER
12 VDC
BATTERY
BLACK WIRE
GROUND WIRES
WHITE WIRE
RED WIRE
TO +12V
DGPS
RECEIVER’S
RECEIVE DATA
WIRE
(IF NEEDED)
GLOBALNAV 310’S
WIRES
GLOBALNAV 310
RECEIVING DATA FROM
A DGPS RECEIVER
GREEN WIRE
DGPS
RECEIVER’S
TRANSMIT
DATA WIRE
