Basic Operation | Elite series
Basic Operation | Elite series
Press the PWR/LIGHT key to access the Backlight
dialog.
Restore defaults
Resets unit options and settings
to defaults.
Advanced Mode
Enables advanced features and settings.
The following features are enabled when Advanced
mode is turned on:
• Navigation (Enables arrival radius, off-
course distance and Bearings setting)
• Alarms (Enables arrival, off course and
anchor alarm options)
• NMEA 0183 Output
• NMEA 2000 (Elite-7 and Elite-9 only)
• Units (Enables distance, speed, depth,
temperature, and bearings options)
Standby mode
Lowers power consumption by
turning o sonar and the display.
NOTE: Leaving your unit in Standby
mode when your boat is not is use will run
down your battery.
