Sonar Operation | Elite series
Sonar Operation | Elite series
Amplitude Scope
Displays the amplitude of the
most recent echo.
Fish ID
Displays sh echoes as sh symbols instead of sh
arches.
Fish ID is not the most accurate
method of sh detection since
structure and suspended debris
may be shown as a sh symbol on
the display.
Downscan options
You can make adjustments to Downscan overlay
settings from the sonar page. Downscan options
are covered in more detail in the DSI section.
Stop Sonar
Prevents the transducer from transmitting to re-
duce/eliminate interference between two sonar
units running on the boat at the same time.
Amplitude
scope
NOTE: The Downscan options menu
will only be available when Downscan
overlay is enabled.
Downscan options menu
NOTE: Sonar history will not be
recorded when sonar is stopped.
