DownScan Operation | Elite series
DownScan Operation | Elite series
Overlay Data
Allows you to select data to
be displayed on top of the
DownScan page.
Overlay data setup is covered
in the Pages section.
Settings
Accesses the Settings menu. Refer to ”Sonar
Settings” on page 23.
Overlay data
Logging Sonar
You can record sonar data and save the le on a
microSD card inserted into the unit’s card reader.
View previously
saved sonar logs
Controls the quality of sonar logs. Higher
quality logs will use more memory.
Stop Sonar
Prevents the transducer from transmitting to re-
duce/eliminate interference between two sonar
units running on the boat at the same time.
NOTE: Sonar history (Trackback) will
not be recorded when sonar is stopped.
