Chapter 4 CPU Function
4 - 9
4.3 Program
4.3.1 Classifications of Program
All functional elements need to execute a certain control process are called as a ‘program’. In PLC
option card, a program is stored in the EEPROM mounted on a CPU module or flash memory of a
external memory module. The following table shows the classification of the program.
Program type Description
Scan program The scan program is executed regularly in every scan
Time-driven
interrupt program
(TDI)
The TDI programs are executed with a constant time interval specified
with parameter setting as below case.
If process time is needed faster than average 1 scan time,
If process time is needed longer than average 1 scan time,
If process time is need ed with constant time interval,
Process driven
interrupt program
(PDI)
The PDI programs are executed when external interrupt input is
applied.
High speed counter
driven interrupt
program (HSCDI)
This interrupt programs are executed when comparison task signal is
applied.
Subroutine
program
The subroutine programs are executed when they are called by the
scan program with a CALL instruction.
