Chapter 6 Usage of Various Functions
6-5
5) Usage
(1) Click twice the parameter on the project window of KGLWIN.
(2) Designate contact point, no. of priority and movement condition of the task program which is
moved by interrupt inputting.
For the details , refer to KGLWIN manual.
Interrupt Type Setting
Interrupt input executing
condition
Rising◎
Falling◎
Rising/Falling◎
Time driven Interrupt
execution periodic set
Time driven Interrupt
execution periodic set
To Next Page
