Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring
7-13
(4) Writing other common area parameters frequently used
(e.g.: acceleration and deceleration times, etc.)
PLC option can write all the common area parameters of inverter.
In this manual, PLC option will set up (write) acceleration and deceleration times.
▶ Inverter common area
Referring to the parameters (exclusively for control) of inverter common area in the “App. 4-6, page 4,
Appendix,” the addresses of the common area of the inverter acceleration and deceleration time are as
follows.
Common Area
Address
Function Detailed Description
0x0383
Acceleration Time Setting of Acceleration Time
0x0384
Deceleration Time Setting of Deceleration TIme
▶ Special D registers of PLC for inverter control corresponding to APO60 ~ 67
Register Use of the Register Remark
D4454
Data to inputted in the common area parameter
address set up by AP060 (PLC Wr Data 1).
PLC option →Inverter (Control)
D4455
Data to inputted in the common area parameter
address set up by AP061 (PLC Wr Data 2).
PLC option →Inverter (Control)
D4456
Data to inputted in the common area parameter
address set up by AP062 (PLC Wr Data 3).
PLC option → Inverter (Control)
D4457
Data to inputted in the common area parameter
address set up by AP063 (PLC Wr Data 4).
PLC option → Inverter (Control)
D4458
Data to inputted in the common area parameter
address set up by AP064 (PLC Wr Data 5).
PLC option → Inverter (Control)
D4459
Data to inputted in the common area parameter
address set up by AP065 (PLC Wr Data 6).
PLC option → Inverter (Control)
D4460
Data to inputted in the common area parameter
address set up by AP066 (PLC Wr Data 7).
PLC option → Inverter (Control)
D4461
Data to inputted in the common area parameter
address set up by AP067 (PLC Wr Data 8).
PLC option → Inverter (Control)
▶ Application and exemplary program
1) Set up inverter parameters as follows; in the APO60 (PLC Wr Data1), enter 0383Hex which is the
common area address (page 4, “App. 4-6, Appendix) of inverter acceleration time, and in the APO61
(PLC Wr Data2), enter 0384Hex which is the common area address (page 4, “App. 4-6, Appendix) of
inverter deceleration time.
Code Function Name Set Value
APO60
PLC Wr Data1
0383 Hex
APO61
PLC Wr Data2
0384 Hex
