INTRODUCTION
The purpose of this manual is to assist you in
maintaining and operating your backhoe. Read
it carefully, it furnishes information and
instructions that will help you achieve years of
dependable performance. Some information may
be general in nature due to unknown and varying
conditions. However, through experience and
these instructions, you should be able to develop
operating procedures suitable to your situation.
"Right" and "Left" as used throughout this manual
are determined by facing the direction the
machine will travel when in use.
The photos, illustrations and data used in this
manual is current at the time of printing, but
due to possible in-line production changes, your
machine may vary slightly in detail.
The manufacturer reserves the right to redesign
the machine as may be necessary without
notification.
▶ Backhoe Components
Terms for backhoe components have some
variations throughout the industry.
▶ Important
Illustrations used in this manual may not show all
safety equipment that is recommended to ensure
safe operation of tractor and backhoe. Refer to
the safety precautions section of this manual for
information concerning safety. consult your dealer
for further information.
▶ Warranty registration
The delivery and warranty registration forms must
be filled out and signed to validate your warranty
protection. The items on the form under "I hereby
Acknowledge" should be read and understood.
The terms and conditions of the warranty on this
machine are specified in the front of this manual.
▶ Serial number and location
The serial number is important information about
the machine and it may be necessary to know it
before obtaining the correct replacement part.
The serial number is located on the bottom right
front of valve cover. The serial number should be
recorded on the delivery and registration form
and below for your reference.
1 Bucket
2 Bucket cylinder
3 Dipper stick
4 Dipper stick cylinder
5 Boom
6 Boom cylinder
7 Swing frame
8 Swing cylinder
9 Main frame and control panel
10 Stabilizer
11 Stabilizer cylinder
Backhoe serial number information
Date purchased
Backhoe serial number
Subframe serial number
Dealer name and telephone number
