BACKHOE MOUNTING
Caution :
Backhoe should be mounted on the proper sub frame assembly.
Caution :
Never store backhoe without bucket attached to the backhoe.
Step 1.
Install the sub frame to the tractor with hardware.
Step 2.
Back tractor slowly toward the backhoe parallel to sub frame assembly, until the couplers on the backhoe
hoses can connect with the hose kit hydraulic couplers or tractor auxiliary couplers located rear of the
tractor. Then, put the couplers to connected.
Step 3.
Set the parking brake of the tractor, make sure the PTO switch is in the off position
Step 4.
Put down the legs(Stabilizer) to the ground and install the backhoe to the sub frame by using boom and
dipper control lever.
