LS tractor LB1300 - IMBH40. Boom Group

48
IMBH40. BOOM GROUP
No.
LS PART NO.
DESCRIPTION
QTY
REMARKS
1-10
-
BOOM – LOWER ASSY
1
1
40427927
BOOM – LOWER
1
2
40427928
PIN
2
3
40427929
PIN
1
4
40427930
HOSE CLAMP HIGH, 4t
1
5
40381867
SPRING WASHER, M8
1
6
40427931
BOLT, M8x30L
1
7
40381517
BOLT, M10x25L
3
8
40381862
PLAIN WASHER, M10
3
9
40381866
SPRING WASHER, M10
3
10
40427919
SNAP RING, Ø28 (Shaft)
3
