15
BACKHOE OPERATION
▶ Swing lock and boom lock
When transporting or dismounting backhoe, you must lock the backhoe's swing and boom.
Position boom straight back and drop pin through holes in swing frame and boom. When not in use,
store pin in hole provided on swing frame and boom.
Observe the following safety warnings when working with your new backhoe/tractor.
Caution :
When using a backhoe, be aware of bucket and boom location always.
When raising an arm (Dipper stick) with bucket rolled forward, material can spill onto non target
area causing injury to assistant or damage other objects.
Caution :
Do not dig near stabilizers. Ground under stabilizers could collapse. Make all movements slow and
gradual when practicing operation.
Caution :
Operate from backhoe operators’ seat only. Pay attention, be ready to stop, immediately in case of
an emergency.
Caution :
To help prevent roll-over, adjust the rear wheels to their widest setting to maximize stability. Refer
to your tractor operator's manual for recommendations.
