LS tractor MT345E - Page 71

3 -5
8
Cruse control drive indicator (HST only)
 This indicator will be turned on when pressing
the cruise control switch to activate the cruise
control drive.
8
9
PTO operation indicator
9
a. Hour meter & Engine diagnosis error code
 If any of errors does not exist on the engine
control, under normal operating conditions,
accumulated operating hours will be displayed.
 It records the hours that your tractor has been
operated regardless of the engine RPM. Use the
hour meter as a guide to determine hourly
service and maintenance intervals.
 The number “0019.1” in hour meter means the
tractor has been used for 19.1hours so far. (19
hours and 6 minutes)
 If any of errors related to the engine control
occurs, the engine diagnosis error codes and
hour meter will be displayed by turns with the
vehicle control error warning light(20) as shown
[Fig2].
 At this time, after escaping from the emergency
area, contact your authorized local dealer for
check.
10
LCD display
Fig.2
20
a
Fig.1
 When the key switch is “ON” position, the PTO mode switch(optional) is placed in “MANUAL”
position and the PTO switch is placed “ON” position, this indicator will be turned on and the rear
PTO will rotate.
 If the PTO mode switch(optional) is “AUTO, this indicator will be turned on when the clutch pedal is
NOT depressed. (For further information, See chapter 3-1-(9), “PTO switch” in this manual.)
7
10
7
High temperature warning indicator
 If the engine coolant temperature goes over the
designated level, this indicator will be turned on.
At this time, stop the engine immediately and
check the engine cooling system including
engine coolant level and engine belt.
 If not cleared, contact your authorized local
dealer for check.
