Chapter 4. Inverter Parameter
4.1 Profibus-DP Communication Parameter List
Code
Number
The name of
Parameter
Initial
Value
Range Definition
CM-06 FBus S/W Ver - -
Indicate the version
of Profibus-DP
communication
module.
CM-07 FBus ID 1 1 ~ 125
Set up the station of
Profibus-DP module.
CM-09 FBus Led - -
Show the ON/OFF
data of the LED on
Profibus-DP
communication
module.
CM-30
ParaStatus
Num
3 0~8
Set up the Status
number for use.
CM-31 Para Status-1 0x000A 0~0xFFFF
Set up Status
address which will be
read by Master.
CM-32 Para Status-2 0x000E 0~0xFFFF
CM-33
Para Status-3
0x000F
0~0xFFFF
CM-34
Para Status-4
0x0000
0~0xFFFF
CM-35
Para Status-5
0x0000
0~0xFFFF
CM-36
Para Status-6
0x0000
0~0xFFFF
CM-37
Para Status-7
0x0000
0~0xFFFF
CM-38
Para Status-8
0x0000
0~0xFFFF
CM-50 Para Ctrl Num 2 0~8
Set up Control
number for use.
CM-51
Para Control-1
0x0005
0~0xFFFF
Set up control
address controlled by
Profibus DP Master.
CM-52 Para Control-2 0x0006 0~0xFFFF
CM-53 Para Control-3 0x0000 0~0xFFFF
CM-54 Para Control-4 0x0000 0~0xFFFF
CM-55 Para Control-5 0x0000 0~0xFFFF
CM-56 Para Control-6 0x0000 0~0xFFFF
CM-57 Para Control-7 0x0000 0~0xFFFF
