4.2.7 Para Control 1~8
It determines that what control information will be sent to inverter
through Profibus-DP communication.
Para Control 1 ~ 8 are set in the form of inverter address.
They set up the address for the common inverter area and the
inverter keypad parameter. If the keypad parameter address is
written, it will be saved in the form of 0x1000 + (‘Group number’ x
0x100) + (‘Code number’).
For example, if Acc Time of No.3 at dr Group is set to Para Control-
1, it has to be set to 0x1103.
0x01 x 0x1000 + 0x01 x 0x100 + 0x03 (Dec 3) = 0x1103
CM-50 Number of Para Control setting
CM-51
~
CM-58
Para Control 1~Control 8 setting
Group
Group Number
dr Group 1
bA Group 2
Ad Group
3
Cn Group
4
In Group
5
OU Group
6
CM Group
7
AP Group
8
Reserved
9
Reserved
10
PRT Group
11
M2 Group
12
