Chapter2. Profibus-DP Communication Module
2
Chapter 2. Profibus-DP Communication Module
2.1 Technical Specification of Profibus-DP Communication
Device Type Profibus DP Slave
Auto Baud rate
Detect
Supported
Synchronization
Mode
Supported
Freeze Mode Supported
Max. Input Length 8 words
Max. Output
Length
8 words
Baud rate Support
9.6K, 19.2K, 93.75K, 187.5K, 500K, 1.5M, 3M,
6M, 12M
Modular Station Supported
Max. Module 2
Max. Connectable
Number of Nodes
Max. 32 nodes without repeater
(including master module)
LED 3 LEDs (ONLINE, ERR, and CPU)
Communication
Connector
9Pin D-sub
Table 1 Technical Data
