Chapter4. Inverter Parameter
18
4.2.6 Number of Para Control setting
It determines that how much control information will be sent to
inverter by Master through Profibus-DP communication.
It can be set up within the range of 0 to 8. Para Control has to be
set as the number of Para Control. (From CM-51 to CM-58 as
preset number)
For example, If CM-50 is set to ‘2’, Para Control should be set from
CM-51 to CM-52. If CM-50 is set to ‘5’, Para Control should be set
from CM-51 to CM-55.
If the number of Para status is changed, set ‘CM-99(Comm Update)’
to ‘1’ to apply the changed number of Para Control to Profibus-DP
communication module.
CM-50 Number of Para Control setting
CM-51
~
CM-58
Para Control 1 ~ Control 8 setting
CM-94 Comm Update
