LS S100 User Manual

Chapter4. Inverter Parameter
17
4.2.5 Para Status 1~8
It determines that what status information will be sent to Master
through Profibus-DP communication.
Para Status 1~8 are set in the form of inverter address. They set up
the address for the common inverter area and the inverter keypad
parameter. If the keypad parameter address is written, it will be
saved in the form of 0x1000 + (‘Group number’ x 0x100) + (‘Code
number’).
For example, if DI Status of No. 90 at n Group are set to Para
Status-1, it should be set to 0x155A.
0x1000 + 0x05 x 0x100 + 0x5A(Dec 90) = 0x155A
CM-30 Number of Para Status setting
CM-31
~
CM-38
Para Status1~Status8 setting
Group
Group Number
dr Group
1
bA Group
2
Ad Group
3
Cn Group
4
In Group
5
OU Group
6
CM Group
7
AP Group
8
(Reserved)
9
(Reserved)
10
PRT Group
11
M2 Group
12
