LS S100 User Manual

Chapter4. Inverter Parameter
15
4.2.3 LED indication for communication status
Profibus-DP communication module has 3 LEDs, ONLINE, ERR,
and CPU on the keypad in order from left to right. It indicates
communication status by LED’s On/Off.
(CM-05 Status Example)
Reserved
ON-LINE
(GREEN)
ERR
(RED)
CPU
(GREEN)
OFF ON OFF ON
(ON)
(OFF)
Reserved ON-LINE ERR CPU
