CHAPTER 7 - OPTIONS
The iS5 series inverter provides many options for various applications. See the following option table and select the
proper options according to your application.
Option Name Description
Sub-A Board
(Extended I/O)
¨ Extended I/O Module
¨ Three Multi-Function Inputs (P4, P5, P6)
¨ Three Multi-Function Outputs (Q1, Q2, Q3)
¨ Auxiliary Analog Frequency Reference (V2)
¨ LM (Load Meter) Output (0 ~ 10V)
Sub-B Board
(Speed Feedback)
¨ Encoder Pulse Input – Speed Feedback (AOC, BOC / A+, A-, B+, B-)
¨ Encoder Pulse Output (FBA, FBB)
¨ Vector control (PG operation) and reference freq via pulse input
Sub-C Board
(Extended I/O)
¨ Extended I/O Module
¨ Three Multi-Function Inputs (P4, P5, P6)
¨ One Multi-Function Outputs (Q1)
¨ Isolated Auxiliary Analog Frequency Reference (V2)
¨ Two Isolated Analog Meter Output (AM1, AM2)
PLC Communication
(F-Net)
¨ Connection with Fnet Communication Module for GLOFA PLC
¨ Inverter Connection: Max. 64
¨ Baud Rate: 1M bps
Internal Installation
Sub Boards
RS-485
¨ RS-485 Communication
¨ Inverter Connection: Max. 32
¨ Baud Rate: Max. 19200 bps
LCD
¨ 32-Character Display
¨ Download and Upload from the Keypad
Keypad
7-Segment ¨ Six Digit 7-Sengment Display
Remote
Cable
Remote Cable ¨ 2m, 3m, 5m long keypad cables for separate keypad installation
DB Resistor ¨ Enables Inverter to decelerate rapidly.
External Installation
Dynamic
Braking
DB Unit ¨ DB units are provided as an option for 40 ~ 100 HP inverters.
☞ Note: Refer to option manual for more details.
