LS SV055iS5-4 User Manual

3
USER SELECTION GUIDE (iS5 SPECIFICATIONS)
230V Class (1 ~ 30HP)
Model Number
(SV xxx iS5 - 2)
008 015 022 037 055 075 110 150 185 220
HP 1 2 3 5 7.5 10 15 20 25 30 Motor
Rating
1
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Capacity
2
[kVA] 1.9 3.0 4.5 6.1 9.1 12.2 17.5 22.9 28.2 33.5
FLA [A] 5 8 12 16 24 32 46 60 74 88
Frequency 0 ~ 400 Hz (Sensorless Vector Control: 0 ~ 300Hz, Sensored Vector Control: 0 ~ 120 Hz)
Output
Ratings
Voltage 200 ~ 230 V
3
Voltage 3 Phase, 200 ~ 230 V (± 10 %) Input
Ratings
Frequency 50 ~ 60 Hz (±5 %)
Braking Circuit On Board On Board
Optional
(DB Resistor)
Optional (DB Resistor)
Max. Braking
Torque
100% 100% 100%
Max. Continuous
Baking Time
5 seconds 5 seconds 15 seconds
Dynamic
Braking
4
Max. Duty 3 % ED 2 % ED
20%,
Continuous
10 % ED
Weight [kg] 4.7 4.7 4.8 4.9 7.7 7.7 13.9 14.4 20 20
230V Class (40 ~ 75HP)
Model Number
(SV xxx iS5 - 2)
300 370 450 550
HP 40 50 60 75 Motor
Rating
1
kW 30 37 45 55
Capacity
2
[kVA] 46 55 68 84
FLA [A] 122 146 180 220
Frequency 0 ~ 400 Hz (Sensorless Vector Control: 0 ~ 300Hz, Sensored Vector Control: 0 ~ 120 Hz)
Output
Ratings
Voltage 200 ~ 230 V
3
Voltage 3 Phase, 200 ~ 230 V (± 10 %) Input
Ratings
Frequency 50 ~ 60 Hz (±5 %)
Braking Circuit Optional (Braking Unit, Resistor)
Max. Braking
Torque
Max. Continuous
Baking Time
Dynamic
Braking
4
Max. Duty
20%, Continuous
Weight [kg] 42 42 61 61
1
Indicates the maximum applicable capacity when using a 4-Pole LG motor.
2
Rated capacity (√3*V*I) is based on 220V for 200V class and 440V for 400V class.
3
Maximum output voltage will not be greater than the input voltage. Output voltage less than the input voltage may be programmed.
4
1~5 HP inverters have internal braking resistors as standard. 7.5~100 HP inverters utilize optional braking resistors.
