LS SV055iS5-4 User Manual

Chapter 5 - Parameter List
77
5.8 Sub-Board Selection Guide According To Function
Sub-Board Type
Code
Function Description LCD Display
SUB-A Board
SUB-B Board
SUB-C Board
EXT-02
Multi-function Input Terminal ‘P4’ P4 define
● ●
EXT-03
Multi-function Input Terminal ‘P5’ P5 define
● ●
EXT-04
Multi-function Input Terminal ‘P6’ P6 define
● ●
EXT-05
V2 Mode Selection V2 mode
● ●
EXT-06
Filtering Time Constant for V2 Input Signal V2 filter
● ●
EXT-07
V2 Input Minimum Voltage V2 volt x1
● ●
EXT-08
Frequency Corresponding to V2 Input
Minimum Voltage
V2 freq y1
● ●
EXT-09
V2 Input Maximum Voltage V2 volt x2
● ●
EXT-10
Frequency Corresponding to V2 Input
Maximum Voltage
V2 freq y2
● ●
EXT-14
Usage for Pulse Input Signal F mode
●
EXT-15
Pulse Input Signal Selection F pulse set
●
EXT-16
Encoder Pulse Selection F pulse num
●
EXT-17
Filtering Time Constant for Pulse Input Signal
F filter
●
EXT-18
Pulse Input Minimum Frequency F pulse x1
●
EXT-19
Frequency Output corresponding to Pulse
Input Minimum Frequency
F freq y1
●
EXT-20
Pulse Input Maximum Frequency F pulse x2
●
EXT-21
Frequency Output corresponding to Pulse
Input Maximum Frequency
F freq y2
●
EXT-22
P-Gain for PG Option PG P-gain
●
EXT-23
I-Gain for PG Option PG I-gain
●
EXT-24
Slip Frequency for PG Option PG Slip freq
●
EXT-30
Multi-function Output Terminal ‘Q1’ Q1 define
● ●
EXT-31
Multi-function Output Terminal ‘Q2’ Q2 define
●
EXT-32
Multi-function Output Terminal ‘Q3’ Q3 define
●
EXT-34
LM (Load Meter) Output Selection LM mode
●
EXT-35
LM Output Adjustment LM adjust
●
EXT-40
AM1 (Analog Meter 1) Output Selection AM1 mode
●
EXT-41
AM1 Output Adjustment AM1 adjust
●
EXT-42
AM2 (Analog Meter 2) Output Selection AM2 mode
●
EXT-43
AM2 Output Adjustment AM2 adjust
●
EXT-50
Speed Limit Level Speed Limit
●
EXT-51
Speed Limit Bias Speed Bias
●
EXT-52
Speed Limit Gain Speed Gain
●
EXT-53
Speed Limit Direction Speed Dir
●
EXT-54
Zero Speed Detection Level ZSD Level
●
EXT-55
Zero Speed Detection Bandwidth ZSD Band
●
EXT-56
Torque Detection Level TD Level
●
EXT-57
Torque Detection Bandwidth TD Band
●
