LSI 3ware 9750 Installation Guide

Chapter 3. Specifications
28 LSI 3ware 9750 SATA+SAS RAID Controller Card Installation Guide
JT5B1 4 Lane
SATA+SAS
connector
(Ports 0-3)
SFF-8087 x4 internal mini SAS
connector.
Connects the controller by cable to SATA
or SAS drives, or a SAS expander.
JT5B2 UART debug
connector
4-pin connector
Reserved for LSI use only.
JT5B3 Reserved for
LSI use only
2-pin connector
Jumper should not be present during
normal operation.
JT6B1 Reserved for
LSI use only
2-pin connector
Jumper should not be present during
normal operation.
JT6B2 Reserved for
LSI use only
2-pin connector
JT6B3 Drive activity
LED
connector
2-pin connector
Connects to an external LED that
indicates drive activity.
Table 7: Jumpers and Connectors for 9750-4i and
9750-8i (continued)
Jumper/
Connector
Type Description
