LSI 3ware 9750 Installation Guide

Jumper and Connector Description for the 9750 Controller Card Family
www.lsi.com/channel/products 29
See Table 8 for a list of jumpers and connectors on the 9750-4i4e
RAID Controller Card. See Figure 3 for the 9750-4i4e card layout.
Table 8: Jumpers and Connectors for 9750-4i4e
Jumper/
Connector
Type Description
J1A1 UART debug
c o n n e c t o r
4-pin connector.
Reserved for LSI use.
J1A2 Reserved for
LSI use
2-pin connector.
Jumper should not be present during
normal operation.
J1A3 Reserved for
LSI use.
2-pin connector.
Jumper should not be present during
normal operation.
J1A4 IPMI-style
I
2
C
connector
3-pin connector.
Supports SES (SCSI enclosure services)
using an internal I
2
C backplane cable.
J1A5 RAID key
connector
2-pin connector.
Enables support for RAID 5
configurations.
Jumper should not be present during
normal operation.
J1B1 4 Lane
SATA+SAS
connector
(Ports 4-7)
SFF-8088 x4 external mini SAS
connector.
Connects the controller by cable to SAS
drives or SATA drives, or a SAS
expander.
